【Equipment Description】

   Mainly suitable for heating PVC, laminating leather mesh fabric with

   embossing treatment, the product is widely used in various industries

   such as shading, waterproof color strip fabric, adver tising, etc

【Technical parameter】

   Composite substrate: PVC, leather mesh fabric, woven fabric

   Composite width: 1600-6000MM

   Mechanical speed: 5-60M/min

   Tension control: manual/automatic tension control

【Control mode】

   Transmission method: connected by a variable frequency motor and

   a reducer for transmission

   Tension system: fully digital tension control, can be manually fine tuned

   Material receiving method: dual station, built-in material collection and

   discharging, with storage rack, non-stop material replacement,

   automatic tension control

   Operation mode: Full line computer PLC module design, centralized

   electrical cabinet, fully digital frequency conversion synchronization,

   Centralized control of touch screen human-machine interface

   Scraper type:double furnace scraper, open furnace coating platform scraper

   Temperature control system: enclosed ver tical furnace, open

   furnace oven, to ensure even drying of products

   Heating method: Gas or energy-saving heating thermal oil can be

   selected for heating

   Safety protection: emergency stop switch, safety protection device

   【Electricity configuration】

    Power supply voltage:   380V+N 50HZ

   Total power: heated kerosene 50KW      Electric heating 180KW

【Other】

•    Using ultrasonic servo for edge alignment

•    Double workstations are used for unwinding, and automatic

     center winding or surface winding is used for winding
